连接器(connector): D-SUB 25Pin Male Solder Black
D-SUB 25Pin Female Solder Black
电缆(wire): UL2919 28AWG*13P+AED PVC JACKET COLOR:BLACK OD= 7.5mm
颜色(color): Black
长度(length): 1M,3M…30M.(Customizable)
电气特性(Electrical characteristics): a)  Contact currect rating: 5 Amp
b)  Dielectric withstanding voltage:500V AC
c)  Insulation resistance: 1MΩ/Min
d)  Contact resistance: 5Ω/Max
e)  Operaion temperature: -25℃～+85℃
产品特点(productfeatures): ●优质纯铜双绞电缆
Pure copper double stranded cable
●双层屏蔽(铜编织)
Double shield (braided copper)
●成型外模更稳定
Molding outside more stable
产品应用(application): 该产品主要用于工业设备,运动控制卡等信号传输.
Industrial equipment, motion control card
环保标准(Environmental standards): Rohs compliant
