Current Rating               :1AMP
Insulator Resistance      :1000MΩ Min.
Contact Resistance        :20mΩ Max.
Voltage Resistance        :AC 500V
Operating Temperature  :-40℃ ～ +105℃
Metallic Material            :Copper alloy
Metal Treatment            :Ni(30~50u")+See  description
Insulator Material           :PA6T/PA9T/LCP UL94V-0
Resistance To Soldering Heat :260°C ±5°C
