Current Rating :8AMP
Insulator Resistance :1000MΩ Min.
Contact Resistance :20mΩ Max.
Voltage Resistance :AC 500V
Operating Temperature :-40℃ ～ +105℃
Metallic Material :Copper alloy
Metal Treatment :Ni(30~50u")+See description
Insulator Material :PA6T/LCP UL94V-0
Resistance To Soldering Heat :260°C ±5°C
PIN数：8P、14P、23P、35P
